    Fuse Holder/fuse base 2.H3-36

    Fuse Holder/fuse base 2.H3-36 Featured Image
    • Fuse Holder/fuse base 2.H3-36

    Short Description:

    Product Name：Fuse Holder/fuse base model：H3-36 Voltage breakdown:AC1500 1minute  insulation resistance: DC 500V 100MΩ M Rating: 30A 32-250VDC Temperature tolerance:-30℃ -150 ℃ Flammability class:UL94V0 Standard: IEC-60335-1 GB_9364.6-2001 Certification: ISO9001, ROHS, Mounting Ways：PCB board installation Material：Hot silicone, brass. Fuse size：Medium insert fuse Application:Applicable to all cars, electric cars, audio and other equipmet


  • FOB Price: US $0.5 - 9,999 / Piece
  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month
  • Port: Shenzhen
  • Payment Terms: L/C,D/A,D/P,T/T
    • Download as PDF

    Product Detail

    Product Tags

    1. Product Name：Fuse Holder/fuse base
    2. model：H3-36
    3. Voltage breakdown:AC1500 1minute
    4. insulation resistance: DC 500V 100MΩ M
    5. Rating: 30A 32-250VDC
    6. Temperature tolerance:-30℃ -150 ℃
    7. Flammability class:UL94V0
    8. Standard: IEC-60335-1 GB_9364.6-2001
    9. Certification: ISO9001, ROHS,
    10. Mounting Ways：PCB board installation
    11. Material：Hot silicone, brass.
    12. Fuse size：Medium insert fuse
    13. Application:Applicable to all cars, electric cars, audio and other equipmet
    16. H3-36
    21. H3-36-1
