    Panel Mount Blade Fuse Holder-H3-40 | HINEW

    Short Description:

    1.Voltage breakdown:AC2500 1minute

    2.insulation resistance:DC 500V 100MΩ M

    3.Rating:10A 250VAC

    4.Temperature tolerance:-20 ° C -150 ° C




  • Cheap fuse holder panel mount:
  • Well and High Quality Control:
  • Prompt Delivery:
  • Customer’s Designs and Logos are Welcome:
  • Competitive Prices:
  • Product Detail

    Product Tags

    The Panel Mount Blade Fuse Holder is ideal for auto or marine applications. This product takes standard blade fuses, rated for 250VAC 10A maximum.

    Quick Details

    1.Product Name:Fuse Blocks and Holders

    2.Model:H3-40

    3.Voltage breakdown:AC2500 1minute

    4.insulation resistance:DC 500V 100MΩ M

    5.Rating:10A 250VAC

    6.Temperature tolerance:-20 ° C -150 ° C

    7.Standard:IEC-60335-1 GB_9364.6-2001

    8.Certification:ISO9001a, ROHS,

    9.Mounting Ways:Panel installation

    10.Material:Thermosetting glue, Huang Tongtong

    11.Fuse size:5*20mm Fuse

    12.Application:It is suitable for panel installation of all electrical and electronic equipment, testing equipment and sound equipment.

    H3-40-1

    Current ratings of fuse wire (from Table 53A of BS 7671: 1992)


    Fuse wire rating (A) Cu Wire diameter (mm)
    3 0.15
    5 0.20
    10 0.35
    15 0.50
    20 0.60
    25 0.75
    30 0.85
    45 1.25
    60 1.53
    80 1.8
    100 2.0
