We introduced the use and function of the car fuse holder in the last article. I believe that many friends have the necessary understanding of it. Today, fuse holder for car car fuse holder wholesaler China Manatee will continue to introduce you to the car fuse holder fuse How to choose.
You May Need these before your order
First, the selection principle of the fuse
1) Determine the type of fuse according to the conditions of use.
2) When selecting the specifications of the fuse, the specification of the melt should be selected first, and then the specification of the fuse should be selected according to the melt.
3) The protection characteristics of the fuse should have a good match with the overload characteristics of the protected object.
4) In the power distribution system, the fuses at all levels should match each other. Generally, the rated current of the upper melt is 2 to 3 times larger than the rated current of the lower melt.
5) For the fuse to protect the motor, attention should be paid to the influence of the starting current of the motor. The fuse is generally only used as a short-circuit protection for the motor, and a thermal relay should be used for overload protection.
6) The rated current of the fuse should not be less than the rated current of the melt; the rated breaking capacity should be greater than the maximum short-circuit current that may occur in the circuit.
Second, the choice of fuse type
The type of fuse is mainly selected according to the condition of the load and the magnitude of the circuit breaking current. For example, for the protection of small-capacity lighting lines or alternators, RC1A series plug-in fuses or RM10 series non-filling sealed tube fuses should be used; Use RL series spiral fuses with high breaking capacity or RT (including NT) series filler-enclosed tubular fuses; for the protection of silicon rectifier devices and thyristors, fast fuses should be used
The selection of fuses is mainly based on the protection characteristics of the load and the size of the short-circuit current. For small-capacity motors and lighting branch lines, fuses are often used as overload and short-circuit protection, so the melting coefficient of the melt is expected to be appropriately small. RQA series fuses of lead-tin alloy melt are usually selected. For larger-capacity motors and lighting trunks, short-circuit protection and breaking capacity should be considered emphatically. RM10 and RL1 series fuses with higher breaking capacity are usually selected; when the short-circuit current is large, RT0 and RTl2 series fuses with current limiting function should be used
The rated current of the melt can be selected as follows:
1) When protecting a stable load without starting process, such as lighting circuit, resistor, electric furnace, etc., the rated current of the melt is slightly greater than or equal to the rated current in the load circuit.
2) The melt current of a motor that protects a single long-term work can be selected according to the maximum starting current, or can be selected according to the following formula
The above is the introduction of how to choose the car insurance seat fuse. If you want to know more about the car insurance seat, please contact us.
